Hose Tail Barb Flange Code 61 90° Long Drop

SKU HTB-F61-90L-1212
Original price $40.90
Original price $40.90 - Original price $408.00
Original price $40.90
Current price $21.60
$21.60 - $215.40
Current price $21.60

Hose Tail Barb Flange Code 61 90° Long Drop – Two-Piece Hydraulic Fitting

The ENGMATTEC Flange Code 61 90° Long Drop Hose Tail is expertly designed for high-pressure hydraulic systems requiring durable, reliable connections. The long drop and 90° configuration make this fitting ideal for routing in compact or challenging layouts, ensuring superior performance under demanding conditions.

Sizes Available:

Compatible with hose sizes from 3/4" to 1 1/2". Flange Code 61 sizes include 3/4", 1", and 1 1/2".

Design Features:

  • Long drop and 90° swept design optimise hose routing in tight or awkward spaces.
  • Constructed from high-strength, corrosion-resistant steel to ensure durability and longevity.
  • Compatible with SAE 100R1, SAE 100R2, R6, and R7 hydraulic hoses.
  • Requires appropriate ferrules (sold separately) for secure assembly.

Applications:

  • Ideal for hydraulic systems in construction equipment, mining machinery, and agricultural machinery.
  • Commonly used in high-pressure fluid transfer systems, hydraulic pumps, motors, and cylinders.
  • Designed for hydraulic setups that utilise Code 61 flanges.

Performance Highlights:

  • Ensures a strong and leak-free connection, even in high-pressure hydraulic applications.
  • Suitable for use with one-wire and two-wire hydraulic hoses.
  • Precision-manufactured to integrate seamlessly with ENGMATTEC and other leading hydraulic hose brands.

Machine Brands Using Flange Code 61 Fittings:

  • Construction Equipment: Caterpillar, Hitachi, and JCB.
  • Agricultural Machinery: John Deere, New Holland, and Massey Ferguson.
  • Mining Equipment: Liebherr, Komatsu, and Sandvik.

Important Notes:

  • This listing is for the hose tail only; ferrules are sold separately.
  • Ensure accurate measurement using calipers or verniers to confirm compatibility with your hydraulic system.
