Hose Tail Barb Flange Code 61 30° Swept

Hose Tail Barb Flange Code 61 30° Swept – Two-Piece Hydraulic Fitting

The ENGMATTEC Flange Code 61 30° Swept Hose Tail is engineered for reliable performance in high-pressure hydraulic applications. This two-piece barb fitting provides a secure and leak-free connection, ideal for demanding hydraulic systems across various industries.

Sizes Available:

Suitable for hose sizes ranging from 3/4" to 1 1/4". Flange Code 61 options include 3/4", 1", and 1 1/4".

Design Features:

• 30° swept design enables streamlined hose routing and reduces stress on the connection.
• Manufactured from high-strength steel with a corrosion-resistant finish to ensure durability and reliability.
• Compatible with SAE 100R1, SAE 100R2, R6, and R7 hydraulic hoses.
• Requires appropriate ferrules (sold separately) for secure assembly.

Applications:

• Commonly used in hydraulic systems for construction, mining, and agricultural machinery.
• Ideal for high-pressure applications in hydraulic pumps, motors, and cylinders.
• Frequently utilised in equipment with Code 61 flange fittings for fluid power systems.

Performance Highlights:

• Designed to withstand high-pressure hydraulic conditions while maintaining a leak-free connection.
• Suitable for both one-wire and two-wire hoses.
• Precision machining ensures compatibility with ENGMATTEC hydraulic hoses and other leading brands.

Machine Brands Using Flange Code 61 Fittings:

• Construction Equipment: Caterpillar, Komatsu, and Volvo.
• Mining Machinery: Liebherr, Hitachi, and Sandvik.
• Agricultural Machinery: John Deere, Massey Ferguson, and Case IH.

Important Notes:

• This listing is for the hose tail only; ensure the correct ferrules are selected for proper assembly.
• Use accurate measuring tools such as calipers or verniers to verify compatibility with your hydraulic system.
